Rc-lang开发周记15 Rust源码学习之desugar
Homura 我摸到了!


pixiv:68232005

这周可以说几乎没写什么代码,都在学习别人的实现。在参考别人的做法之前自己写一版比较合适,这样会对整体有个了解(这样有利于阅读代码),知道哪些地方会有问题,看别人的代码后会发现哪里不一样并且去思考差异。不过我之前已经写过简易的实现了,因此直接来参考Rust的实现了

本周看的内容一半是desugar,另一半是关于MIR的。讲解的话目前先讲一下desugar的内容,内容相对较少能够一篇讲完。MIR的东西非常多,笔记也没有整理好,之后会单独开启一个源码阅读系列的坑

在讲之前首先要提的是为什么要学习他人的实现。尽管写出来能跑是没有问题的,但是参考这样的项目的过程中能学到他人写代码的方式,学到更多不一样的实现方式

desugar

是什么

我们现在在使用的编程语言中有一些语法糖,这些语法糖本质上是对一些功能的包装,让我们用的更方便,但是没有做到一些什么没有这个语法糖所做不到的东西。

这里举一个很直观的例子,ruby中有一个关键字是unless,它的功能是如果false则执行第一个分支,否则执行第二个分支,相当于if !cond

为什么需要

上面也提到了只是包装,那么可能多种不同形式的语法糖都是针对同一种功能,像C语言中的while和for本质都是一个loop(Rust的for并不是,后面会提到这种for的desugar过程)

desugar的过程是将这些都转换为了更本质的东西,我觉得这属于一种“去重”的过程。还是上面的例子,假设需要对loop做优化,没有desugar的情况下我们需要对while和for两者都进行处理,两者又有轻微的差别,导致实现起来更不方便,每个优化都需要对这些细节做处理,那不如直接全部转换成一种形式来处理处理

关于Rust的文档中的介绍是这样

This means many structures are removed if they are irrelevant for type analysis or similar syntax agnostic analyses.

Rust的实现

官方的文档介绍

https://rustc-dev-guide.rust-lang.org/lowering.html

在这里我要给Rust一个好评,开发文档比较详细,而且一些注释也相对容易懂一些。后面的很多东西都会以注释为参考讲了大概做了什么,注意这里我们的目的并不是搞清楚细节,而是搞清楚都做了什么操作,所以细节部分点到为止,细节深究下去是无底洞,有兴趣可以去源码处深入看一下

desugar相关代码不特别说明根目录都是rustc_ast_lowering

读代码之前需要了解的

了解了这些能够更容易看明白代码

  1. 各种参数更多是使用ir来标识以及获取的
  2. span用于记录源码相关信息
  3. arean.alloc是用于分配构建ir的,看实现的时候不需要在意这里的细节,只需要看传进去的IR

DesugaringKind

这个类型在rustc_span/src/hygine.rs中

实际使用的时候主要用于创建span的时候填入相关信息,因此并没有放到ast_lowering的位置

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
pub enum DesugaringKind {
/// We desugar `if c { i } else { e }` to `match $ExprKind::Use(c) { true => i, _ => e }`.
/// However, we do not want to blame `c` for unreachability but rather say that `i`
/// is unreachable. This desugaring kind allows us to avoid blaming `c`.
/// This also applies to `while` loops.
CondTemporary,
QuestionMark,
TryBlock,
/// Desugaring of an `impl Trait` in return type position
/// to an `type Foo = impl Trait;` and replacing the
/// `impl Trait` with `Foo`.
OpaqueTy,
Async,
Await,
ForLoop,
LetElse,
WhileLoop,
}

先不考虑Async和Await,我们来一个个说其他的

CondTemporary

这部分都在src/expr.rs中

我们先来看一下它的调用位置,发现是在manage_let_cond这个函数中

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
// If `cond` kind is `let`, returns `let`. Otherwise, wraps and returns `cond`
// in a temporary block.
fn manage_let_cond(&mut self, cond: &'hir hir::Expr<'hir>) -> &'hir hir::Expr<'hir> {
fn has_let_expr<'hir>(expr: &'hir hir::Expr<'hir>) -> bool {
match expr.kind {
hir::ExprKind::Binary(_, lhs, rhs) => has_let_expr(lhs) || has_let_expr(rhs),
hir::ExprKind::Let(..) => true,
_ => false,
}
}
if has_let_expr(cond) {
cond
} else {
let reason = DesugaringKind::CondTemporary;
let span_block = self.mark_span_with_reason(reason, cond.span, None);
self.expr_drop_temps(span_block, cond, AttrVec::new())
}
}

转换条件

根据函数名和参数我们可以得知这个是处理cond不为let的情况下,既然是cond那么应当会出现在while和if中

实现

实际查看manage_let_cond的usage也正是如此。这两处的处理都是类似的,因此我选取一段来介绍

1
2
let lowered_cond = self.lower_expr(cond);
let new_cond = self.manage_let_cond(lowered_cond);

可以看到十分简单,就是先对cond本身lower,然后再对整个cond lower

然后我们再回到manage_let_cond的实现中

根据实现可以看到对expr递归判断,如果包含let则直接返回原始cond,否则进行转换

span_block是用于记录信息的,关键在expr_drop_temps中

本质行为

进入实现可以看到

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
/// Wrap the given `expr` in a terminating scope using `hir::ExprKind::DropTemps`.
///
/// In terms of drop order, it has the same effect as wrapping `expr` in
/// `{ let _t = $expr; _t }` but should provide better compile-time performance.
///
/// The drop order can be important in e.g. `if expr { .. }`.
pub(super) fn expr_drop_temps(
&mut self,
span: Span,
expr: &'hir hir::Expr<'hir>,
attrs: AttrVec,
) -> &'hir hir::Expr<'hir> {
self.arena.alloc(self.expr_drop_temps_mut(span, expr, attrs))
}

pub(super) fn expr_drop_temps_mut(
&mut self,
span: Span,
expr: &'hir hir::Expr<'hir>,
attrs: AttrVec,
) -> hir::Expr<'hir> {
self.expr(span, hir::ExprKind::DropTemps(expr), attrs)
}

实际做的事情就是转换为了DropTemps这种类型的Expr

QuestionMark

是什么

QuestionMark是Result为Err或者Option为None的时候直接抛出错误的一种语法糖,摘选一段官方的例子

1
2
3
4
5
6
7
8
9
10
11
12
13
#![allow(unused_variables)]
fn main() {
use std::num::ParseIntError;
fn try_to_parse() -> Result<i32, ParseIntError> {
let x: i32 = "123".parse()?; // x = 123
let y: i32 = "24a".parse()?; // returns an Err() immediately
Ok(x + y) // Doesn't run.
}

let res = try_to_parse();
println!("{:?}", res);
assert!(res.is_err())
}

查看QuestionMark的usage,找到了lower_expr_try这个函数

做了什么

先来看注释,这里的注释可以说是非常清楚了,将一个QuestionMark转换为了一个模式匹配

1
2
3
4
5
6
7
8
9
10
11
12
/// Desugar `ExprKind::Try` from: `<expr>?` into:
/// ```rust
/// match Try::branch(<expr>) {
/// ControlFlow::Continue(val) => #[allow(unreachable_code)] val,,
/// ControlFlow::Break(residual) =>
/// #[allow(unreachable_code)]
/// // If there is an enclosing `try {...}`:
/// break 'catch_target Try::from_residual(residual),
/// // Otherwise:
/// return Try::from_residual(residual),
/// }
/// ```

实现

函数签名

1
fn lower_expr_try(&mut self, span: Span, sub_expr: &Expr) -> hir::ExprKind<'hir>

既然是返回了一个match,那么我们先看一下Expr::Match的结构

1
2
3
/// A `match` block, with a source that indicates whether or not it is
/// the result of a desugaring, and if so, which kind.
Match(&'hir Expr<'hir>, &'hir [Arm<'hir>], MatchSource)

根据注释的内容看上去分为三个部分

  1. Try::branch()

非常直接的操作,直接lower传进来的sub_expr

1
2
3
4
5
6
7
8
9
10
11
12
// `Try::branch(<expr>)`
let scrutinee = {
// expand <expr>
let sub_expr = self.lower_expr_mut(sub_expr);

self.expr_call_lang_item_fn(
unstable_span,
hir::LangItem::TryTraitBranch,
arena_vec![self; sub_expr],
None,
)
};
  1. ControlFlow::Continue(val)
1
2
3
4
5
6
7
8
// `ControlFlow::Break(residual) =>
// #[allow(unreachable_code)]
// return Try::from_residual(residual),`
let break_arm = {
... // 省略
let break_pat = self.pat_cf_break(try_span, residual_local);
self.arm(break_pat, ret_expr)
};

这里的arm是构建了hir的Match的Arm参数

  1. ControlFlow::Break(residual)
1
2
3
4
5
6
7
8
// `ControlFlow::Break(residual) =>
// #[allow(unreachable_code)]
// return Try::from_residual(residual),`
let break_arm = {
... // 省略
let break_pat = self.pat_cf_break(try_span, residual_local);
self.arm(break_pat, ret_expr)
};

和上面差不多,细节都在省略的部分

在实际的处理中在最前面的有一部分像上面的CondTemporary一样,先创建一个span用于记录源码相关的信息,源码不再赘述

还会创建一个*#[allow(unreachable_code)]* 供后面的match使用

1
2
3
4
5
6
7
8
9
10
11
let attr = {
// `allow(unreachable_code)`
let allow = {
let allow_ident = Ident::new(sym::allow, self.lower_span(span));
let uc_ident = Ident::new(sym::unreachable_code, self.lower_span(span));
let uc_nested = attr::mk_nested_word_item(uc_ident);
attr::mk_list_item(allow_ident, vec![uc_nested])
};
attr::mk_attr_outer(allow)
};
let attrs = vec![attr];

TryBlock

在lower_expr_try_block中被用到

做了什么

这里的注释解释的比较清楚了,我就不再赘述

1
2
3
/// Desugar `try { <stmts>; <expr> }` into `{ <stmts>; ::std::ops::Try::from_output(<expr>) }`,
/// `try { <stmts>; }` into `{ <stmts>; ::std::ops::Try::from_output(()) }`
/// and save the block id to use it as a break target for desugaring of the `?` operator.

最终都是转换为一个包含stmts和::std::ops::Try::from_output的block

实现

我们从返回值往上看,可以看到返回了一个Block,Block的第二个参数是Label,这里并不需要因此设置为了None

那么我们顺着第一个参数block往上看来源,又回到了函数的开始

和注释所讲的一样,根据是否有一个expr来做两种不同的处理方式,也是比较直观的实现

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
fn lower_expr_try_block(&mut self, body: &Block) -> hir::ExprKind<'hir> {
self.with_catch_scope(body.id, |this| {
let mut block = this.lower_block_noalloc(body, true);

// Final expression of the block (if present) or `()` with span at the end of block
let (try_span, tail_expr) = if let Some(expr) = block.expr.take() {
(
this.mark_span_with_reason(
DesugaringKind::TryBlock,
expr.span,
this.allow_try_trait.clone(),
),
expr,
)
} else {
let try_span = this.mark_span_with_reason(
DesugaringKind::TryBlock,
this.sess.source_map().end_point(body.span),
this.allow_try_trait.clone(),
);

(try_span, this.expr_unit(try_span))
};

let ok_wrapped_span =
this.mark_span_with_reason(DesugaringKind::TryBlock, tail_expr.span, None);

// `::std::ops::Try::from_output($tail_expr)`
block.expr = Some(this.wrap_in_try_constructor(
hir::LangItem::TryTraitFromOutput,
try_span,
tail_expr,
ok_wrapped_span,
));

hir::ExprKind::Block(this.arena.alloc(block), None)
})
}

OpaqueTy

OpaqueTy是什么

OpaqueTy是impl Trait的一种别名,看一下这个例子

1
type Foo = impl Bar;

实际参数使用Foo的时候只能使用Bar中的接口,不论实现了Bar的类型是否实现了其他类型

lower做了什么

关于这个lower的操作,在DesugaringKind::OpaqueTy的位置写的非常清楚了,只是做了简单的类型替换

1
2
3
/// Desugaring of an `impl Trait` in return type position
/// to an `type Foo = impl Trait;` and replacing the
/// `impl Trait` with `Foo`.

lower操作

lower操作在lower_opaque_impl_trait这个函数中(src/lib.rs)

1
2
3
4
5
6
7
8
9
fn lower_opaque_impl_trait(
&mut self,
span: Span,
fn_def_id: Option<LocalDefId>,
origin: hir::OpaqueTyOrigin,
opaque_ty_node_id: NodeId,
capturable_lifetimes: Option<&FxHashSet<hir::LifetimeName>>,
lower_bounds: impl FnOnce(&mut Self) -> hir::GenericBounds<'hir>,
) -> hir::TyKind<'hir>

来看一下返回值的部分,可以看到主要处理分为两部分,一部分是处理ID相关的,另一部分是处理lifetime

1
2
3
// `impl Trait` now just becomes `Foo<'a, 'b, ..>`.
hir::TyKind::OpaqueDef(hir::ItemId { def_id: opaque_ty_def_id }, lifetimes)
}

这里也就不展开了,上面的细节很多是关于type相关的,这部分我不了解,内容也比较长。

lower_opaque_impl_trait这个函数则是被在上面的lower_ty_direct()调用

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
...
TyKind::ImplTrait(def_node_id, ref bounds) => {
let span = t.span;
match itctx {
ImplTraitContext::ReturnPositionOpaqueTy { fn_def_id, origin } => self
.lower_opaque_impl_trait(
span,
Some(fn_def_id),
origin,
def_node_id,
None,
|this| this.lower_param_bounds(bounds, itctx),
),
ImplTraitContext::TypeAliasesOpaqueTy { ref capturable_lifetimes } => {
// Reset capturable lifetimes, any nested impl trait
// types will inherit lifetimes from this opaque type,
// so don't need to capture them again.
let nested_itctx = ImplTraitContext::TypeAliasesOpaqueTy {
capturable_lifetimes: &mut FxHashSet::default(),
};
self.lower_opaque_impl_trait(
span,
None,
hir::OpaqueTyOrigin::TyAlias,
def_node_id,
Some(capturable_lifetimes),
|this| this.lower_param_bounds(bounds, nested_itctx),
)
}
...

可以看到这里的TypeKind为ImplTrait且ImplTraitContext为TypeAliasesOpaqueTy或者ReturnPositionOpaqueTy的时候才会做这个desugar操作

  • 这里我其实不是很明白。。

ImpltraitContext

来看一下ImpltraitContext,根据Disallowed注释大意和成员可以得知这个类主要关联了一个位置是否可以使用impl trait

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
/// Context of `impl Trait` in code, which determines whether it is allowed in an HIR subtree,
/// and if so, what meaning it has.
#[derive(Debug)]
enum ImplTraitContext<'b, 'a> {
/// Treat `impl Trait` as shorthand for a new universal generic parameter.
/// Example: `fn foo(x: impl Debug)`, where `impl Debug` is conceptually
/// equivalent to a fresh universal parameter like `fn foo<T: Debug>(x: T)`.
///
/// Newly generated parameters should be inserted into the given `Vec`.
Universal(&'b mut Vec<hir::GenericParam<'a>>, LocalDefId),

/// Treat `impl Trait` as shorthand for a new opaque type.
/// Example: `fn foo() -> impl Debug`, where `impl Debug` is conceptually
/// equivalent to a new opaque type like `type T = impl Debug; fn foo() -> T`.
///
ReturnPositionOpaqueTy {
/// `DefId` for the parent function, used to look up necessary
/// information later.
fn_def_id: LocalDefId,
/// Origin: Either OpaqueTyOrigin::FnReturn or OpaqueTyOrigin::AsyncFn,
origin: hir::OpaqueTyOrigin,
},
/// Impl trait in type aliases.
TypeAliasesOpaqueTy {
/// Set of lifetimes that this opaque type can capture, if it uses
/// them. This includes lifetimes bound since we entered this context.
/// For example:
///
/// ```
/// type A<'b> = impl for<'a> Trait<'a, Out = impl Sized + 'a>;
/// ```
///
/// Here the inner opaque type captures `'a` because it uses it. It doesn't
/// need to capture `'b` because it already inherits the lifetime
/// parameter from `A`.
// FIXME(impl_trait): but `required_region_bounds` will ICE later
// anyway.
capturable_lifetimes: &'b mut FxHashSet<hir::LifetimeName>,
},
/// `impl Trait` is not accepted in this position.
Disallowed(ImplTraitPosition),
}

而在上面只有ReturnPositionOpaqueTy和TypeAliasesOpaqueTy的情况下可以使用,当然从名字就可以看出来这两种情况就是为了OpaqueTy而设计的

ForLoop

调用处的函数签名

1
2
3
4
5
6
7
8
fn lower_expr_for(
&mut self,
e: &Expr,
pat: &Pat,
head: &Expr,
body: &Block,
opt_label: Option<Label>,
) -> hir::Expr<'hir> {

注释写的非常详细了,将一个ForLoop转换为一个iterator操作

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
/// Desugar `ExprForLoop` from: `[opt_ident]: for <pat> in <head> <body>` into:
/// ```rust
/// {
/// let result = match IntoIterator::into_iter(<head>) {
/// mut iter => {
/// [opt_ident]: loop {
/// match Iterator::next(&mut iter) {
/// None => break,
/// Some(<pat>) => <body>,
/// };
/// }
/// }
/// };
/// result
/// }
/// ```

实现比较长就不贴了,想要了解更详细的可以去源码处查看

LetElse

什么情况会转换

在lower_let_else中被调用,而这个lower_let_else则是在lower_stmts中

这是lower_stmts中的处理代码,可以看到是InitElse的情况下会进行处理

1
2
3
4
5
6
7
8
9
10
11
let mut expr = None;
while let [s, tail @ ..] = ast_stmts {
match s.kind {
StmtKind::Local(ref local) => {
let hir_id = self.lower_node_id(s.id);
match &local.kind {
LocalKind::InitElse(init, els) => {
let e = self.lower_let_else(hir_id, local, init, els, tail);
expr = Some(e);
// remaining statements are in let-else expression
break;

注意这里的break

来看一下InitElse

1
2
3
4
5
6
pub enum LocalKind {
...
/// Local declaration with an initializer and an `else` clause.
/// Example: `let Some(x) = y else { return };`
InitElse(P<Expr>, P<Block>),
}

实现

函数签名

1
2
3
4
5
6
7
8
fn lower_let_else(
&mut self,
stmt_hir_id: hir::HirId,
local: &Local,
init: &Expr,
els: &Block,
tail: &[Stmt],
) -> &'hir hir::Expr<'hir> {

一开始看到函数签名中的tail产生了一些疑惑,不知道用途是什么。一开始想到的是会往里添加东西,但是一看类型是immutable的(传进来的是一个array的slice),后面看到调用处的break才明白过来,具体用途后面会讲到

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
fn lower_let_else(
&mut self,
stmt_hir_id: hir::HirId,
local: &Local,
init: &Expr,
els: &Block,
tail: &[Stmt],
) -> &'hir hir::Expr<'hir> {
let ty = local
.ty
.as_ref()
.map(|t| self.lower_ty(t, ImplTraitContext::Disallowed(ImplTraitPosition::Variable)));
let span = self.lower_span(local.span);
let span = self.mark_span_with_reason(DesugaringKind::LetElse, span, None);
let init = self.lower_expr(init);
let local_hir_id = self.lower_node_id(local.id);
self.lower_attrs(local_hir_id, &local.attrs);
let let_expr = {
let lex = self.arena.alloc(hir::Let {
hir_id: local_hir_id,
pat: self.lower_pat(&local.pat),
ty,
init,
span,
});
self.arena.alloc(self.expr(span, hir::ExprKind::Let(lex), AttrVec::new()))
};
let then_expr = {
let (stmts, expr) = self.lower_stmts(tail);
let block = self.block_all(span, stmts, expr);
self.arena.alloc(self.expr_block(block, AttrVec::new()))
};
let else_expr = {
let block = self.lower_block(els, false);
self.arena.alloc(self.expr_block(block, AttrVec::new()))
};
self.alias_attrs(let_expr.hir_id, local_hir_id);
self.alias_attrs(else_expr.hir_id, local_hir_id);
let if_expr = self.arena.alloc(hir::Expr {
hir_id: stmt_hir_id,
span,
kind: hir::ExprKind::If(let_expr, then_expr, Some(else_expr)),
});
if !self.sess.features_untracked().let_else {
feature_err(
&self.sess.parse_sess,
sym::let_else,
local.span,
"`let...else` statements are unstable",
)
.emit();
}
if_expr
}

我们从返回值向上看,可以看到if_expr的参数是let_expr, then_expr, else_expr

  1. let_expr的部分转成了HIR的let
1
2
3
4
5
6
7
8
9
10
let let_expr = {
let lex = self.arena.alloc(hir::Let {
hir_id: local_hir_id,
pat: self.lower_pat(&local.pat),
ty,
init,
span,
});
self.arena.alloc(self.expr(span, hir::ExprKind::Let(lex), AttrVec::new()))
};

我们来看一下定义和注释

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
/// Represents a `let <pat>[: <ty>] = <expr>` expression (not a Local), occurring in an `if-let` or
/// `let-else`, evaluating to a boolean. Typically the pattern is refutable.
///
/// In an if-let, imagine it as `if (let <pat> = <expr>) { ... }`; in a let-else, it is part of the
/// desugaring to if-let. Only let-else supports the type annotation at present.
#[derive(Debug, HashStable_Generic)]
pub struct Let<'hir> {
pub hir_id: HirId,
pub span: Span,
pub pat: &'hir Pat<'hir>,
pub ty: Option<&'hir Ty<'hir>>,
pub init: &'hir Expr<'hir>,
}

pub enum ExprKind<'hir> {
...
/// A `let $pat = $expr` expression.
///
/// These are not `Local` and only occur as expressions.
/// The `let Some(x) = foo()` in `if let Some(x) = foo()` is an example of `Let(..)`.
Let(&'hir Let<'hir>),
...
}
  1. then_expr
1
2
3
4
5
let then_expr = {
let (stmts, expr) = self.lower_stmts(tail);
let block = self.block_all(span, stmts, expr);
self.arena.alloc(self.expr_block(block, AttrVec::new()))
};

这里解答了我对传进来的tail的疑惑。这里的意思是then的话那么会继续lower tail的部分,将这部分插入到then的block中

  1. else_expr
1
2
3
4
let else_expr = {
let block = self.lower_block(els, false);
self.arena.alloc(self.expr_block(block, AttrVec::new()))
};

这里将传进来的els(InitElse的else block)lower到了一个block

实际做了什么转换

单个看起来可能不够直观,将三个部分组合起来的话这个逻辑就是

cond中创建了一个expr bind

true:将后面的stmts lower到一个新的block中(因此外面需要break)

false:将els的部分lower到block

false为什么不lower tail

像我一样不了解这里语法的情况会觉得false的行为很奇怪,false就不走tail了吗

于是我就写了这样的一个用例

1
2
3
4
5
6
7
#![feature(let_else)]
fn main() {
let y:Option<i32> = None;
let Some(x) = y else {
println!("fail") };
println!("test");
}

直接报了编译错误,else中的内容是要强制从当前函数返回才行

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
error[E0308]: `else` clause of `let...else` does not diverge
--> src/main.rs:4:26
|
4 | let Some(x) = y else {
| __________________________^
5 | | println!("fail") };
| |__________________________^ expected `!`, found `()`
|
= note: expected type `!`
found type `()`
= help: try adding a diverging expression, such as `return` or `panic!(..)`
= help: ...or use `match` instead of `let...else`

For more information about this error, try `rustc --explain E0308`.
error: could not compile `playground` due to previous error

WhileLoop

在lower_expr_mut中被调用,在外部创建span信息然后在lower_expr_while_in_loop_scope中实际进行lower

1
2
3
4
5
6
7
8
9
...
ExprKind::While(ref cond, ref body, opt_label) => {
self.with_loop_scope(e.id, |this| {
let span =
this.mark_span_with_reason(DesugaringKind::WhileLoop, e.span, None);
this.lower_expr_while_in_loop_scope(span, cond, body, opt_label)
})
}
...

做了什么

注释也非常易懂,将一个while转换为一个loop加一个,cond作为一个if,cond为false则break

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// We desugar: `'label: while $cond $body` into:
//
// ```
// 'label: loop {
// if { let _t = $cond; _t } {
// $body
// }
// else {
// break;
// }
// }
// ```
//
// Wrap in a construct equivalent to `{ let _t = $cond; _t }`
// to preserve drop semantics since `while $cond { ... }` does not
// let temporaries live outside of `cond`.

实现

实际的实现代码也是非常直接,没什么可讲的

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
fn lower_expr_while_in_loop_scope(
&mut self,
span: Span,
cond: &Expr,
body: &Block,
opt_label: Option<Label>,
) -> hir::ExprKind<'hir> {
let lowered_cond = self.with_loop_condition_scope(|t| t.lower_expr(cond));
let new_cond = self.manage_let_cond(lowered_cond);
let then = self.lower_block_expr(body);
let expr_break = self.expr_break(span, ThinVec::new());
let stmt_break = self.stmt_expr(span, expr_break);
let else_blk = self.block_all(span, arena_vec![self; stmt_break], None);
let else_expr = self.arena.alloc(self.expr_block(else_blk, ThinVec::new()));
let if_kind = hir::ExprKind::If(new_cond, self.arena.alloc(then), Some(else_expr));
let if_expr = self.expr(span, if_kind, ThinVec::new());
let block = self.block_expr(self.arena.alloc(if_expr));
let span = self.lower_span(span.with_hi(cond.span.hi()));
let opt_label = self.lower_label(opt_label);
hir::ExprKind::Loop(block, opt_label, hir::LoopSource::While, span)
}

最后

本来以为desugar的东西比较少就想都写完,但是越写发现越多,这还忽略了很多细节上的东西,导致了文章比较长

在读代码的时候一开始我是没看到DesugaringKind这个类型的,想着既然要lower,那么首先将ast和hir的定义进行比较。由于内容比较多,只选了熟悉的Expr和Stmt进行对比。查看实际有哪些成员发生了变化,之后再去找到实现的位置。查看实现的过程中偶然看到DesugaringKind,之后看的过程就顺畅了许多

  • 本文标题:Rc-lang开发周记15 Rust源码学习之desugar
  • 本文作者:Homura
  • 创建时间:2022-04-17 14:23:11
  • 本文链接:https://homura.live/2022/04/17/rc-lang-dev/rc-lang-dev-15/
  • 版权声明:本博客所有文章除特别声明外,均采用 BY-NC-SA 许可协议。转载请注明出处!
